ICON Vehicle Dynamics – Suspension System

Description

The ICON Vehicle Dynamics Stage 10 suspension system (SKU K53300TS) combines active IIC (ICON Intelligent Control) suspension and triple rate rear coil springs for the Toyota Tacoma 2.4T. The 2.5in CDEV remote reservoir coilovers feature an electronic valve that adjusts compression damping near-instantaneously based on onboard sensor data. The system is controlled via the IIC smartphone app and operates autonomously once configured. Tubular UCAs with the patented Delta Joint PRO (U.S. Pat. 10,731,700) correct front-end geometry and eliminate CV bind. Triple rate progressive rear coil springs deliver on-road comfort and off-road bottoming resistance. Tubular rear lower links with FK rod ends and dual-durometer bushings complete the kit. Front lift 1.25 to 3in, rear lift 0.5in.

Specifications

• Brand/Manufacturer: ICON Vehicle Dynamics
• SKU/Reference: K53300TS
• Front Lift: 1.25 to 3 in
• Rear Lift: 0.5 in
• Front & Rear Shock Diameter: 2.5 in (Aluminum Series)
• Reservoir Style: Remote (front and rear)
• Suspension Type: Active (IIC) – electronic CDEV valve adjustment
• Rear Spring Rate: Triple Rate Progressive
• Tubular UCAs with Delta Joint PRO (90°, U.S. Pat. 10,731,700)
• Materials: 6061 aircraft-grade aluminum, CAD plated corrosion resistant
• Compatibility: Toyota Tacoma 2.4T, 4WD, rear coil spring models (See Application Section)
• Recommended Tires: 33" x 11.50" (fender trimming may be required for larger sizes)
• Condition: New
• Sold and shipped by Truck Expert
